Infinity Hemorrhoid Probe

Definitive treatment of 3rd and 4th degree hemorrhoids by gentle and well controlled laser energy emission at low peak temperature in the tissue. This achieves a shrinking and fibrotization with limiting complications and preserving anoderm and the mucous membrane which results in restoring the natural anatomical structure.

The specially designed pointed tip and structure of the Infinity Hemorrhoid Probe can be inserted into the hemorrhoidal package without incision avoiding open wounds and excisions.

Technical Features

  • Fiber core diameter: 600 µm
  • Connector with SMA 905 standard or freestanding ferrule
  • Customized connector with logo printing possible
  • Optical fiber jacket: white ETFE
  • High-transmission efficiency for all common medical wavelengths: 980 nm to 1940 nm
  • Double-packed in sterile pouches
  • 5-year sterile shelf life

Technical details

  • Outer diameter (tip): 1.8 mm
  • Core diameter: 600 μm typically
  • Standard length: 2.5 m
  • Wavelength e.g: 980 nm to 1940 nm
  • Typical transmission: 98%
  • Emission: cylindrical and conical
  • Custom designs available according to customer specifications
Download brochure

Lightguide Infinity Side Fiber

Recent innovations made by Lightguide result in our best laser fiber for soft tissue laser surgery. The broad cylindrical 360° laser light emission of our Infinity Side Fiber ensures smooth and gentle laser energy delivery to the target tissue. Intravascular, intrastitial and intracutaneous laser ablation treatments can benefit from the smoother procedure and higher patient comfort.

The optimized fused fiber tip design guarantees first-class safety and durability. The optical fiber has marking lines to ease positioning in the target tissue. A compatible Introducer Set for vascular access is available.

Benefits

  • Gentle energy transfer with lowest peak temperature
  • Most uniform emission
  • Cylindrical 360˚ emission profile
  • 100% direct irradiation to the target
  • Reduced sticking to tissue
  • Fused fiber tip design for highest safety

Technical details

  • Outer diameter (tip): 1.24 mm, 1.6 mm or 1.8 mm
  • Standard length: 2.5 m
  • Wavelength e.g: 980 nm – 2100 nm
  • Diffusing length: 4 mm
  • Core diameter: 400 μm or 600 μm typically
  • Custom design: according to customer’s specification
Download brochure

Lightguide Infinity Fistula Probe

The Infinity Fistula Probe is specially designed to be inserted into an anal fistula or pilonidal sinus tract to distribute the laser energy circumferentially directly to the epothelized tissue.

It therefore ensures a homogeneous thermal destruction of the fistula tract.

The optimized fused fiber tip design guarantees first-class safety and durability. The optical fiber has dedicated marking lines to ease precise positioning of the fiber tip within the anal fistula or pilonidal sinus tract.

Technical Features

  • Fiber core diameter: 545 µm
  • Connector with SMA 905 standard or freestanding ferrule
  • Customized connector with logo printing possible
  • Optical fiber jacket: white ETFE with black centimeter marking
  • High-transmission efficiency for all common medical wavelengths: 980 nm to 2100 nm
  • Double-packed in sterile pouches
  • 5-year sterile shelf life

Technical details

  • Outer diameter (tip): 1.6 mm
  • Standard length: 2.5 m
  • Wavelength: 980 nm to 2100 nm
  • Typical transmission: 98%
  • Diffusing length: 4 mm
  • Core diameter: 545 μm typically
  • Custom designs available according to customer specifications
Download brochure

Lightguide Hemorrhoid Probe

The conical probe can be introduced into the pile without incision, leaving no open wounds. This product has maximum efficacy in the wavelength range of 810 nm up to 1940 nm.

The compatible Dual LuerLock Handpiece and an introducer with depth markers is available as an accessory product to ease the treatment.

Technical Features

  • Fiber core diameter: 545 µm
  • Connector with SMA 905 standard or freestanding ferrule
  • Customized connector with logo printing possible
  • Optical fiber jacket: white ETFE
  • High-transmission efficiency for all common medical wavelengths: 810 nm, 980 nm, 1470 nm and 1940 nm
  • Double-packed in sterile pouches
  • 5-year sterile shelf life

Technical details

  • Outer diameter (tip): 1.8 mm
  • Core diameter: 545 μm
  • Standard length: 2.5 m
  • Wavelength: 200 nm to 2200 nm
  • Typical transmission: 98%
  • Emission angle: forward directed cone
  • Numerical aperture: 0.22
  • Custom designs available according to customer specifications
Download brochure

Lightguide Dual LuerLock Handpiece

Technical Features

  • Suitable for fiber tip diameters or fiber jacket diameters of up to 2 mm
  • Length: 13 cm
  • material color: stainless steel or black PPSU
  • Custom designs available according to customer specifications
